HL-850UE 5G Indoor CPE with WiFi 6 AX1800
- Chipset: Unisoc V620, quad-core Cortex-A55 up to 2.0GHz
- 5G Rate: Up to 5.47Gbps DL (NSA) / 4.67Gbps DL (SA)
- WiFi: WiFi 6 AX1800, dual-band 2.4GHz / 5GHz, Mesh
- Ports: 2× Gigabit Ethernet LAN; optional RJ11 VoLTE
- Software: OpenWrt 24.10 with VPN and firewall
- Management: TR-069, Web UI and remote FOTA/OTA
Product Description
The HL-850UE 5G indoor CPE combines a cellular modem, router and WiFi 6 AX1800 access point in a desktop unit for fixed wireless access. Check cellular reception, operator requirements and the ordered configuration for each installation.
The HL-850UE is a 5G indoor router and 5G indoor CPE that combines 5G SA/NSA cellular connectivity with dual-band WiFi 6 AX1800 in a compact desktop enclosure. As a 5G indoor FWA terminal, it lets operators deliver fixed wireless broadband to homes, offices and retail sites where fiber or cable is unavailable. Powered by the Unisoc V620 quad-core platform, it supports 5G download rates of up to 5.47Gbps in NSA mode and 4.67Gbps in SA mode, with LTE and WCDMA support.
Dual-band 2.4GHz and 5GHz WiFi, 2×2 MU-MIMO and Mesh support connect home and office devices, while two Gigabit Ethernet LAN ports provide wired access. Optional RJ11 VoLTE and eSIM configurations are available.
OpenWrt 24.10 provides multiple VPN tunnels, firewall controls, automatic or manual APN setup and static routing. TR-069 central management, local Web UI and remote FOTA/OTA updates simplify device administration. A watchdog and link self-recovery help maintain connectivity.
Maximum data rates are theoretical; actual performance depends on the network, signal conditions and connected devices.
Indoor 5G fixed wireless access
The HL-850UE is an indoor 5G customer-premises router for fixed wireless access (FWA). It connects a cellular broadband service to local WiFi and Ethernet devices in homes, offices and retail premises.
Technical Specifications
Download HL-850UE 5G Indoor CPE Specification (PDF, 4 pages)
Specifications below are based on the linked product datasheet. DC input is 12V. Confirm the supplied adapter rating and peak power requirements for the ordered configuration. Maximum cellular and WiFi rates are theoretical, not guaranteed end-to-end throughput.
| Chipset | Unisoc V620, quad-core ARM Cortex-A55 up to 2.0GHz |
|---|---|
| Network Standard | 3GPP Release 16; 5G NR SA/NSA, LTE FDD/TDD and WCDMA |
| 5G NR Bands | n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78 |
| LTE Bands | FDD B1/3/5/7/8/20/28/32; TDD B38/40/41/42/43 |
| WCDMA Bands | B1/5/8 |
| 5G Maximum Data Rate | NSA: 5.47Gbps DL / 825Mbps UL; SA: 4.67Gbps DL / 1.25Gbps UL |
| LTE Maximum Data Rate | 1.6Gbps DL / 211Mbps UL; DL Cat 19 / UL Cat 18 |
| MIMO | 5G NR: DL 4×4 / UL 2×2 on supported bands; LTE: DL 4×4 on supported bands |
| WiFi | WiFi 6 AX1800; IEEE 802.11a/b/g/n/ac/ax; 2.4GHz and 5GHz |
| WiFi Features | Mesh, AP mode, DFS and 2×2 MU-MIMO; more than 32 users |
| WiFi Channel Width | 2.4GHz: 20/40MHz; 5GHz: 20/40/80MHz |
| WiFi Security | WPA2-PSK (AES); WPA/WPA2-PSK (TKIP/AES) |
| Interfaces | 2× Gigabit Ethernet LAN; USB 2.0; optional RJ11 VoLTE |
| SIM | 1× SIM slot, 1.8V/3V; optional eSIM |
| Operating System | OpenWrt 24.10 |
| Management | Local Web UI, TR-069 central management, remote FOTA/OTA firmware updates and SSH |
| Routing & Security | Multiple VPN tunnels, automatic/manual APN, multi-APN, static routes, firewall and NAT/port mapping |
| Connection Recovery | Automatic dialing, link self-recovery and watchdog |
| Power Supply | DC 12V |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -10°C to +55°C |
| Humidity | 5%–95%, non-condensing |
| Enclosure | White ABS; IP30; desktop placement |
| Dimensions | 170 × 160 × 32mm |
| Weight | 520g |
| Indicators & Controls | Power / Network / WiFi LEDs; Reset and WPS / Mesh controls |
| Cellular Antennas | 2 external and 2 internal 4G/5G antennas; 4×4 MIMO, 50Ω |
| 5G MIMO Bands | DL 4×4: n1/n3/n7/n28/n38/n40/n41/n77/n78; UL 2×2: n40/n41/n77/n78 |
| LTE MIMO Bands | DL 4×4: B1/B3/B7/B28/B32/B38/B40/B41/B42/B43 |
| Ethernet ESD Protection | Contact discharge ±4kV; air discharge ±8kV |
5G Indoor Router Use Cases
- Home broadband: share cellular internet with WiFi and Ethernet devices.
- Small offices: connect computers and office devices with dual-band WiFi 6 and Gigabit LAN.
- Retail and chain stores: deploy indoor connectivity with central device management.
- Temporary workspaces: provide cellular broadband where a wired connection is unavailable.
Why Choose the HL-850UE 5G Indoor Router
- 5G SA/NSA support: flexible cellular connectivity with LTE and WCDMA support.
- WiFi 6 AX1800: dual-band wireless access with Mesh and MU-MIMO.
- Wired connectivity: two Gigabit Ethernet LAN ports.
- Remote management: TR-069 and FOTA/OTA updates.
- Compact design: 170 × 160 × 32mm desktop enclosure.
Interested in HL-850UE 5G Indoor Router with WiFi 6 AX1800?
Contact Honlly Telecom for pricing, sample availability, optional configurations and project requirements.Product Selection & OEM/ODM Support
Buyer Questions
For deployment, confirm target operator bands, local network compatibility, required management features and optional RJ11 VoLTE or eSIM configuration with Honlly Telecom.
FAQ
What is a 5G indoor router?
A 5G indoor router is a customer-premises gateway that converts 5G cellular signals into Ethernet and WiFi for indoor use. The HL-850UE is a 5G indoor router designed for homes, offices and retail locations.
Is the HL-850UE a 5G Indoor FWA device?
Yes. The HL-850UE works as a 5G indoor FWA terminal, letting operators deliver fixed wireless broadband to a fixed indoor location over 5G.
Is the HL-850UE a 5G Indoor CPE?
Yes. As 5G indoor CPE (customer premises equipment), it combines the modem, router and WiFi access point in one desktop unit for operator self-install deployments.
Does the HL-850UE support 5G SA and NSA?
Yes. It supports 5G SA and NSA, plus LTE FDD/TDD and WCDMA fallback.
Does it support WiFi 6 and Mesh?
Yes. The HL-850UE supports dual-band WiFi 6 AX1800, Mesh and 2×2 MU-MIMO.
Which interfaces and bands are available?
It has two Gigabit Ethernet LAN ports and USB 2.0, with optional RJ11 VoLTE and eSIM. 5G NR bands: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78; LTE FDD/TDD bands.
Is this router designed for outdoor installation?
No. The HL-850UE is an IP30 indoor desktop router (0°C to +50°C). For outdoor use, see Honlly’s 5G outdoor CPE models.
What information is useful for a quotation?
Please provide your target market, required cellular bands, quantity, and any optional interface or firmware requirements.
Indoor placement or an outdoor CPE?
The HL-850UE is an IP30 indoor desktop router. Evaluate signal quality at the intended indoor location before deployment. If the project requires an outdoor receiving unit connected to an indoor WiFi router, compare the HL-6300R outdoor CPE kit and confirm its installation requirements with Honlly Telecom.
Planning a deployment for your market
For projects in Yemen, Southeast Asia, Africa, Central America or North America, share the deployment location, operator, required quantity and network requirements when requesting a quotation. Review the selected model’s published bands against the intended service, and confirm the ordered hardware and firmware configuration before sample evaluation. Band overlap alone does not establish operator compatibility or local approval.
Discuss SIM and APN settings, power arrangements, installation conditions, remote management and any applicable approval requirements before volume procurement. Request a current quotation for the required configuration; pricing and delivery terms should be confirmed for each order.
HL-850UE deployment checklist
Confirm the deployment country, operator bands and SA/NSA network requirements before selecting an indoor 5G CPE. Review the listed Ethernet, WiFi and voice interfaces against the intended installation; optional features and firmware support should be confirmed for the ordered variant.
